Moion Drive Technology Products
Ready For Production. Ready for Integration. Ready for Application.
What we oFFER
YOUR BENEFIT
PROFIT FROM A PROVEN TECHNOLOGY SYSTEM
Full Flexibility
Benefit from a fully customizable hardware and software architecture that can be rapidly adapted to your specific application and requirements.
Accelerated Innovation
Validate new technologies in a real vehicle environment and reduce development cycles from concept to industrialization.
Reduced Risk
Leverage a functionally safe and production-ready platform to validate innovations before investing in full-scale product development.
OUR Products
Proven drive technology
Vehicle generation 2 & 3
ELECTRIC drive axle
Highly integrated battery assembly from a 40-ton electric truck with a fuel cell range extender
800 V platform, 410 kW cont. engine power, 3160 Nm cont. torque, 5400 Nm peak torque
Proven in a road-licensed prototype vehicle
Tested in the vehicle according to ECE R100 and ECE R10
Functional Safety concept according to ISO 26262, including ASIL C measures, AC phase monitoring, and a dedicated monitoring control unit
3-speed transmissions, 2 modular motors, integrated inverter and high-voltage PDU
VEHICLE GENERATION 2
High-Voltage Battery System
Highly integrated battery assembly from a 40-ton electric truck with a fuel cell range extender
800 V battery system with 368 kWh capacity
Proven and validated in a road-licensed prototype vehicle
Tested and validated according to ECE R100 and ECE R10
Master BMS and integrated power electronics
BMS developed up to ASIL C
Battery cell chemistry: LFP
Cell manufacturer: CATL
Vehicle generation 3
Fuel cell System Integration
Highly integrated battery assembly from a 40-ton electric truck with a fuel cell range extender
Includes production-ready LV and HV wiring harnesses
Includes highly integrated piping and tubing for thermal management and fluid systems
Components: 2 fuel cell systems, 2 DC/DC converters, Air compressor, Coolant pump
Proven in a road-licensed prototype vehicle
Tested in the vehicle according to ECE R100 and ECE R10
VEhicle Generation 2
High-Voltage Power Distribution Unit (PDU)
High-voltage Power Distribution Unit (PDU) for systems up to 800 V
Validated in a road-licensed prototype vehicle
Tested in the vehicle according to ECE R100 and ECE R10
Integrated high-voltage switching and power distribution
Customizable configuration for relays, connectors and power ratings
VEHicle Generation 1
High-Voltage Power Distribution Unit (PDU)
High-voltage Power Distribution Unit (PDU) for systems up to 800 V
Validated in a prototype vehicle on the test track
Proven in a road-licensed prototype vehicle
Cost-efficient design based on a standard housing
Flexible architecture with an interchangeable, laser-machined interface plate
Configurable according to application-specific requirements
INSiGHTS
Take a Look into our Technology
engineering & Development
DISCOVER our TEchnology Services
Battery
From battery technology assessment to industrialized production: engineering, validation and manufacturing solutionsacross the entire battery value chain.
E-Motor
Engineering efficient, scalable andcost-competitive electric drive solutions from concept to production.
Fuel Cell
Enabling the hydrogen economy throughfuel cell and electrolyzer engineering, validation and industrialization.
Heavy-Duty & Off-Highway Vehicles
Delivering electrified heavy-duty and off-highway vehicles through system integration, validation and industrial implementation.
